Surface Slitting Machine

Contact Now

Product Application

is surface rewind type slitting machine mainly fit for foil ,paper and film slitting and rewinding, especially it is fit for narrow width slitting materials. The finish roll with good tension and smooth edge side.

Product Features

  1. This machine adopts center rewinding and surface contact mode to rewinding.
  2. Main Motor equipped with inverter for speed regulation
  3. Automatic EPC for unwinding, photocell is suitable for tracking the edge and/or the line of material.
  4. Equipped with air shaft for unwinding material loading, magnetic powder brake
  5. Auto tension controller optional
  6. Air shaft for rewinding (frictional cam shaft available for option), Magnetic powder clutch for rewinding tension control
  7. Equipped with air trim blowing system.
  8. Automatic metering,

Technical Parameters

Model  700  1100  1300
Max Material Width 700mm 1100mm 1300mm
Slitting and Rewinding Speed 160m/min
Mechanical Speed  180m/min
Max Dia of Material  ф600mm
Max Dia of Rewinding  Ф450mm
Internal Dia of Roll Core  ф76mm ( ф156mm 可选)
Width of Final Roll 30-700mm 30-1100mm 30-1300mm
Tolerance of EPC ±0.5mm
Total Power 4.5Kw 5Kw 5.5Kw
Weight 1200KG 1500KG 1800KG
Dimension  L2000×W1110×H1400mm  L2400×W1110×H1400mm  L2600×W1110×H1400mm
