Honeycomb Paper Making Machine Roll to Sheet

Contact Now

Use

1. This machine is suitable for die cutting honeycomb paper, wrapping paper, shock-absorbing paper, kraft paper, fish net paper from 70-100gsm

2. The unwinding, cutting and rewinding in one process

3. Main motor equipped with inverter for speed regulation

4. Tension controlled automaticlly by magnetic powder brake and clutch, both is 10kgs

5. Automatic meter counting device, automatically stop after it reaches the length you set

6. Pneumatic cylinder to control the cutting module up and down

7. Optinal part: Automatic lifting system in unwinding and web guiding system



Model SLFW-B520
Max material width 510mm
Machine working speed 0-120m/min
Unwinding diameter Max.1300mm
Rewinding diameter Max.350mm
Unwinding roll weight Max.1Ton
Unwinding shaft 3"
Rewinding shaft 1" / 1.5" / 2"
Machine power 4kw
Power supply 380v-415v, 50-60Hz
Dimensions(mm) 2900 xc 1900 x 1500mm
Machine weight 1500kg
